High Torque 17nm Low Speed Good Quality 83mm Brushed with Worm Gear Box 12V24V 150W

Product Name: High Torque 17nm Low Speed Good Quality 83mm Brushed with Worm Gear Box 12V24V 150W SEO Description: We are a factory that specializes in high-quality, low-speed brushed worm gear box motors with a torque of 17nm and power of 150W for 12V or 24V systems.
Request a Quote

PRODUCTS DETAILS

Basic Info.

Model NO.
BG 83ZYT01
Structure and Working Principle
Brush
Type
Z2
Certification
CCC, FCC
Brand
Bg Motor
Product Name
83mm Brushed DC Motor
Keywords
Worm Gear Motor
Rated Voltage
12V
Color
Black
Motor Diameter
83mm
Noise
65dB
Shaft Type
Can Be Choosen
Bearing
Ball
Power
150W
Rotation Direction
Ccw and Cw
Transport Package
EPE Foam + Carton + Pallet
Specification
2.5kg
Trademark
BG MOTOR
Origin
Zhejiang, China
Production Capacity
20000PCS /Year

Product Description

High Torque 17nm Low Speed Good Quality 83mm Brushed with Worm Gear Box 12V24V 150W
BG 83ZYT DC Brushed Motor
Environmental Conditions -20ºC~50ºC
Insulation Clase B
Protection class IP44
Noise ≤65dB
Number of phases Single
Lifespan >1000h



Electrical Specifications
Model RATED LOAD NO LOAD   STALL
 Voltage   Power    Speed    Torque    Current  Speed  Current   Torque  Current
V W rpm N.m A rpm A   N.m   A
BG 83ZYT116  12 150 25 17 13 32 3    51   39
We can also customize products according to customer requirements.

High Torque 17nm Low Speed Good Quality 83mm Brushed with Worm Gear Box 12V24V 150W

High Torque 17nm Low Speed Good Quality 83mm Brushed with Worm Gear Box 12V24V 150W
High Torque 17nm Low Speed Good Quality 83mm Brushed with Worm Gear Box 12V24V 150W
High Torque 17nm Low Speed Good Quality 83mm Brushed with Worm Gear Box 12V24V 150W
High Torque 17nm Low Speed Good Quality 83mm Brushed with Worm Gear Box 12V24V 150W
High Torque 17nm Low Speed Good Quality 83mm Brushed with Worm Gear Box 12V24V 150W
High Torque 17nm Low Speed Good Quality 83mm Brushed with Worm Gear Box 12V24V 150W
High Torque 17nm Low Speed Good Quality 83mm Brushed with Worm Gear Box 12V24V 150W
High Torque 17nm Low Speed Good Quality 83mm Brushed with Worm Gear Box 12V24V 150W
Established in 1994, Ningbo BG Motor Factory is a professional manufacturer of brushless DC motors, brushed DC motors, planetary gear motors, worm gear motors, Universal motors and AC motors. We have a plant area of 6000 square meters, multiple patent certificates, and we have the independent design and development capabilities and strong technical force, with an annual output of more than 1 million units. Since the beginning of its establishment, BG motor has focused on the overall solution of motors. We manufacture and design motors, provide professional customized services, respond quickly to customer needs, and actively help customers to solve problems. Our motor products are exported to 20 countries, including the United States, Germany, Italy, the United Kingdom, Poland, Slovenia, Switzerland, Sweden, Singapore, South Korea etc.
Our founder, Mr. Sun, has more than 40 years of experience in motor technology, and our other engineers also have more than 15 years of experience, and 60% of our staff have more than 10 years of experience, and we can assure you that the quality of our motors is top notch.
The products cover AGV, underwater robots, robots, sewing machine industry, automobiles, medical equipment, automatic doors, lifting equipment, industrial equipment and have a wide range of applications.
We strive for excellence in the quality of each product, and we are only a small and sophisticated manufacturer.
Our vision: Drive the world forward and make life better!

High Torque 17nm Low Speed Good Quality 83mm Brushed with Worm Gear Box 12V24V 150W

Q:1.What kind of motors can you provide?

A:At present, we mainly produce brushless DC motors, brush DC motors, AC motors, Universal Motors; the power of the motor is less than 5000W, and the diameter of the motor is not more than 200mm;

Q:2.Can you send me a price list?

A:For all of our motors, they are customized based on different requirements like lifetime, noise,voltage,and shaft etc. The price also varies according to annual quantity. So it's really difficult for us to provide a price list. If you can share your detailed requirements and annual quantity, we'll see what offer we can provide.

Q:3.Can l get some samples?

A:It depends. If only a few samples for personal use or replacement, I am afraid it'll be difficult for us to provide because all of our motors are custom made and no stock available if there are no further needs. If just sample testing before the official order and our MOQ,price and other terms are acceptable,we'd love to provide samples.

Q4:Can you provide OEM or ODM service?

A:Yes,OEM and ODM are both available, we have the professional R&D dept which can provide professional solutions for you.

Q5:Can l visit your factory before we place an order?

A:welcome to visit our factory,we are very pleased if we have the chance to know each other more.

Q:6.What's the lead time for a regular order?

A:For orders, the standard lead time is 15-20 days and this time can be shorter or longer based on the different model,period and quantity.
